What Your Thermostat
Isn’t Telling You

In a large shop or barn, air temperature and building temperature are two completely different numbers. Only one of them tells the truth about what’s happening inside your building.

See the Proof ↓ Contact Us

Real Data. Same Day. Same Weather.

Two shops. One January night at −35°C.

These surface temperatures were measured the same day, in the same extreme cold, at two real working shops in Western Canada — not in a lab.

Hydronic Underfloor Heating

Wilson Colony Shop

January 2017 — Outside: −35°F / −37°C

Surface	°F	°C
Floor	69.9	21.1
Metal Wheel	59.6	15.3
Tractor	55.7	13.2
Tire	54.9	12.7
Concrete Wall	51.1	10.6
Metal Door	42.1	5.6

~28°F spread

Hot floor. Cold everything else. Moisture forming on every cold surface.

Reflect-O-Ray Overhead Radiant

Evergreen Colony Shop

January 2017 — Outside: −35°F / −37°C

Surface	°F	°C
Vac Truck	68.2	20.1
Truck	67.4	19.7
Ceiling	65.6	18.7
Floor near Door	65.6	18.7
Wall	63.5	17.5

Under 5°F spread

Entire building within range. No cold surfaces. No condensation. No freeze-ups.

The thermostat in both shops was satisfied. The buildings were telling completely different stories. Surface temperature is what the building actually is. Air temperature is what the thermostat reads.

What Reflect-O-Ray Is

Heat the building.
Not just the air.

Most heating systems warm the air and rely on convection to carry that warmth through the space. In a small room that works. In a large shop or barn — with cold walls, overhead doors, heavy equipment, and ceilings that trap warm air before it ever reaches the work zone — the air loses.

Reflect-O-Ray is a low-intensity infrared radiant tube heating system. It delivers energy as infrared waves that interact directly with surfaces — walls, doors, equipment, steel, concrete. Those surfaces absorb it, warm up, and re-radiate heat back into the space. The building itself becomes the heat source.

That’s why every surface in the Evergreen shop reads within a few degrees of every other. Not because the air is hot — because the mass is warm.

3–6Minutes to radiant output

30–50%Less fuel vs conventional

3–4°FTypical surface spread

140 ftMax run, burner to exhaust fan

System Options

Built for the building,
not the other way around.

Three tube diameters, each matched to a different type of environment. The system scales to the space.

3.5″

EDS 3.5

Precision-controlled environments where surface temperature uniformity is critical. Poultry barns, calf barns, stables, show facilities — anywhere animal comfort and even heat distribution are non-negotiable. Front-end intensity tunable with thermal control tubing. One of the few systems of its kind on the market.

Low Ceiling Precision

4″

EDS 4.0

The commercial and agricultural workhorse. Large shops, vehicle and equipment facilities, warehouses, agricultural buildings. Delivers the radiant reach and balanced output that large open volumes demand. Stainless steel available for corrosive environments.

Shops Agriculture Commercial

6″

EDS 6.0

Built for high-bay. Aircraft hangars, large industrial facilities, and any space where ceiling height demands extended radiant travel before exhaust. When the building is big, the system needs to match it.

High Bay Industrial Hangars

Available in natural gas, propane, oil-fired (3.5″ EDS), and stainless steel for corrosive environments.

The Reflect-O-Ray Advantage

Quicker. Faster. Further. Stronger. Safer.

⚡

Quicker

Effective radiant output in 3–6 minutes — not the hours a hydronic slab needs after a cold start or an open door.

↻

Faster

When a door opens at −35°C the building responds from mass that’s already warm. Rebuilding heat from the floor up every time isn’t recovery — it’s starting over.

↔

Further

Vacuum venting draws output along the full tube length. Multi-burner runs to a single exhaust cover distances and patterns that linear systems can’t reach.

💪

Stronger

Low-mass aluminized spiral tubing transfers heat efficiently along the entire run. Balanced emissivity. No hot front. No dead rear. Usable heat throughout.

🛡

Safer

Pressure differential monitoring detects any change in system integrity — a damaged tube, a physical impact, anything. The flame shuts down immediately. A pressure system running hot has no equivalent protection.
